EQUIPMENT設備
● 全自動收料系統
主機尺寸：
( 長 * 寬 * 高 )2200mm*2000mm*1600mm
平穩快速收杯
PLC 程序自動化控制，自動變頻
配備計數裝置可設置任意數量
鋁合金外框，不銹鋼操作臺，精美耐用
EQUIPMENT 設備
AUTO CUP COLLECTOR 全自動收料系
WORKING PRINCIPLE
Fully automatically cup collection(restacking). With this equipment, customer can save huge labor cost for
manually collect the cups one by one by hand.
On this automatic cup restacker, cups will continue to be conveyed to the auto cup collector one by one,after the
cups label shrinked by the heat shrink tunnel.
The absorption unit will quickly absorb the vertical cups which completed the label shrink by the tunnel, so that
the cups will be collected into horizontal stack.
During the cup stacking, the sensor will work and count the cup numbers, when fulfill a certain set number for one
stack, the stack will be separated by the separate unit and loaded into the chain conveyor.
特點
全自動收杯系統 , 告別手工收杯，降低勞動力成本，大大提高杯子套標整線的生產效率。
杯子標簽在完成自動套標及電熱爐收縮后通過輸送帶被傳送至自動收杯系統，通過特制收杯裝置自動將單個杯子自動堆放成列，計數
裝置自動計數，達到設置好的數量后自動分杯，成列進入后段集杯槽，待下一步收納裝箱。
MAIN FEATURE
Frame Dimension:
(L*W*H)2200mm*2000mm*1600mm
Collecting Number Setting Available
Stainless Steel Collecting Platform
Smooth and fast cup restacking
PLC programming and invertor insi
機器介紹
