EQUIPMENT設備
● 電熱收縮爐
主機尺寸：1700L x 500W x 1700H mm
整機納米級防指紋不銹鋼殼體
三位立體內循環熱風系統
溫度風量可任意調節
適應各種尺寸形狀的杯型
耐超高溫定制網鏈輸送
電壓：3 相 380 V
總功率：9KW
適應收縮膜材質 PVC, PET, OPS
溫度精度控制范圍 +/- 2 度
全程均勻收縮
EQUIPMENT 設備
ELECTRIC HEAT PF-SH1700
SHRINK TUNNEL 電熱收縮爐
TECHNICAL PARAMETER
Main machine size: 1700L x 500W x 1700H mm
Whole Stainless Steel Body
Blow Air Frequency Controlled
Wider Entrance and Exit, More Cups into it which makes the whole line speed faster
Recirculating air from Up and Down, lower temperature and better shrinkage of the cup
Suitable for All kinds of cups shrink, No need to adjust the height when changing cups
11meter TEFLON chain, up to 350℃ heat resistance
Solid body Frame, Stronger and more stable
Weight: about 300kg
Voltage: 3 phase 380 / 220V
Blower power: 9KW
Suitable for shrink variety container shapes, circle, square, oval-shaped, and curve-shaped etc
Accurately temperature control with +/- 5 degr
